Speedway Motors Universal High-Tech Corvette-Style Master Cylinder, 1 Inch Bore, Compatible with Power or Manual Brake Systems, Compact Build and Includes Plugs for Unused Ports

These high-tech Corvette-style master cylinders were designed using OE specifications and 100% tested.  They have a 1" bore and are suited for disc/drum combinations. Each master cylinder is ported on both the left and right sides, allowing for installation in many different applications. This exclusive design features a mating flange that works with applications requiring 3-1/8” through 3-3/8” bolt patterns.  These master cylinders will work with manual or power brake systems and can be quickly changed with the included adapter pin to plug the deep well.  The wide body and low profile gives this master cylinder the clearance you need when installing in tight areas and yet it maintains a large volume of fluid necessary for 2 and 4 wheel disc brake applications. 1" bore. 3/8"-24 IFF outlet ports on both sides. Plugs are included for the unused ports. Mount spacing is 3-3/8", accommodates 3-1/8" applications. Works with power or manual brake systems. Compact, for installation under the floor or on the firewall. Suited for either disc/disc or disc/drum combinations. Stroke of this master cylinder is approximately 1-1/16" Has a piston adaptor that will allow for power or manual applications. Learn more about selecting the proper master cylinder for your vehicle by reading our tech article.Brake System Selection.

• Versatile Application: Suitable for both power and manual brake systems, these master cylinders can be installed in a variety of applications thanks to 3/8"-24 IFF outlet ports on both sides and included plugs for unused ports.
• OE Specification Design: High-tech Corvette-style master cylinders designed using OE specifications and 100% tested for quality assurance, promising reliable performance.
• Perfect for Disc/Drum Combos: With a 1" bore, these master cylinders are ideal for disc/drum combinations, providing the right balance of power and control for your braking system.
• Flexible Installation: Features a compact design for installation under the floor or on the firewall, and a unique design with a mating flange that accommodates applications requiring 3-1/8” through 3-3/8” bolt patterns.
• High Capacity: Despite their compact size, these master cylinders maintain a large volume of fluid necessary for 2 and 4 wheel disc brake applications, ensuring optimal brake performance.
